Sand Casting

  Services for sand casting Traditional craftsmanship, superior quality casting A traditional and incredibly adaptable metal casting method, sand casting can be used to produce a wide range of metals. Our business offers top-notch sand casting services using cutting-edge machinery and skilled artisans to satisfy a wide range of client demands.

Product Description

Our sand casting capabilities:

  We can handle a range of casting operations, from little parts to huge and intricate components, thanks to our top-notch sand casting equipment and skilled casting crew. We are experts at fusing cutting-edge technology with age-old craftsmanship to deliver castings to clients that have superior mechanical qualities and aesthetic appeal

Sand casting: We provide coated sand casting, resin sand casting, and green sand casting, all of which are capable of producing castings in a range of sizes and shapes. A quick production cycle and low cost make sand casting an excellent choice for casting a variety of metals.

Precision casting: To minimize the need for additional processing, we employ precision sand technology to create castings with excellent surface quality and dimensional accuracy.

Large casting: To satisfy the demands of the heavy industry sector, we are able to cast intricate and sizable parts, including pump bodies, machine tool beds, and wind power equipment components.


Sand casting materials:

CategoryParameters
Casting Materials
  • Common materials: Gray cast iron, ductile iron, carbon steel, stainless steel, aluminum alloy, copper alloy, brass.
  • Material weight range: 0.5 kg - 10,000 kg
    • Casting Dimensions
  • Maximum casting size: 5000 mm x 5000 mm x 4000 mm
  • Minimum casting size: 50 mm x 50 mm x 30 mm
  • Casting thickness: 5 mm - 500 mm
    • Casting Precision
  • Dimensional tolerance: ±1.5 mm - ±5 mm (depending on casting size)
  • Surface roughness: Ra 6.3 µm - 25 µm
    • Casting Process
  • Mold types: Sand molds, resin sand, clay sand.
  • Pouring methods: Manual pouring, automatic pouring.
  • Core making methods: Cold core, hot core, clay sand core.
    • Heat Treatment Capability
  • Heat treatment processes: Normalizing, annealing, quenching, tempering.
  • Treatment furnace temperature range: 800℃- 1200℃
    • Post-Processing
  • Surface treatment: Shot blasting, sandblasting, machining, painting, powder coating.

    • To satisfy the demands of various fields, we can cast a range of materials:

      Gray iron: is used extensively in the production of engine blocks, machine tools, and other items due to its high wear resistance and casting performance.

      Ductile iron: is ideal for structural components that must support heavy loads because of its exceptional strength and durability.

      Cast steel: is ideal for producing highly sought-after mechanical parts because of its exceptional strength and resistance to wear.

      Aluminum alloy: is used extensively in aerospace, automotive, and other industries because it is lightweight and resistant to corrosion.

      Copper alloy: Good electrical and thermal conductivity makes copper alloy ideal for heat exchangers and other electrical components.


    Testing and quality control:

      We employ stringent quality control procedures throughout the sand casting process. To make sure that each casting's internal quality and dimensional correctness satisfy client specifications, we use spectrometers, ultrasonic testing, X-ray testing, and other testing tools. Depending on the needs of the client, we can additionally offer extra heat treatment services to enhance the castings' mechanical qualities.

    Mold creation and design:

     From mold design to casting manufacturing, we offer comprehensive services. In order to guarantee that the castings have good mechanical qualities and casting performance, our technical team will collaborate closely with customers to optimize mold design. In accordance with the unique needs of our clients, we are also able to provide customized casting solutions.

    Why pick us?

    • Rich process experience: years of sand casting expertise guarantee that every casting satisfies exacting requirements.
    • Cutting-edge machinery and technology: integrating contemporary technology with conventional methods to guarantee the caliber and productivity of castings.
    • Strict quality control: every stage, from raw materials to final goods, is rigorously examined to guarantee product quality.
    • Customer customization service: providing custom casting solutions to satisfy a range of unique needs based on the needs of the customers.

    Get in touch with us

     Please get in touch with us right away if you're searching for a trustworthy supplier of sand casting services. To ensure the success of your project, we will offer you expert advice and first-rate casting production services.
